The common transmission convergence (ComTC) layer for Higher Speed Passive Optical Networks is defined as part of the FEC in the ITU-T G.9804.2 Recommendation. The Creonic ITU 25G PON LDPC Encoder and Decoder support the default LDPC (17280, 14592) coding scheme, as well as the optional LDPC (17152, 14592) scheme. The IP cores are available for ASIC and FPGAs.
Creonic GmbH
Key Features
- Support for code rates 38/45 and 57/67
- Uncoded block size of 14592 bits
- Compliant with “Higher speed passive optical networks – Common transmission convergence layer specification, Recommended Standard, ITU-T G.9804.2, October 2021”
Offering Brief
Offering Brief
| Device Family | Agilex® 3 FPGA C-Series, Agilex® 5 FPGA D-Series, Agilex® 5 FPGA E-Series, Agilex® 7 FPGA F-Series, Agilex® 7 FPGA I-Series, Agilex® 7 FPGA M-Series, Agilex® 9 FPGA Direct RF-Series, Arria® 10 GT FPGA, Arria® 10 GX FPGA, Arria® 10 SX FPGA, Arria® V GT FPGA, Arria® V GX FPGA, Arria® V GZ FPGA, Arria® V ST FPGA, Arria® V SX FPGA, Cyclone® 10 GX FPGA, Cyclone® 10 LP FPGA, Cyclone® V E FPGA, Cyclone® V GT FPGA, Cyclone® V GX FPGA, MAX® 10 FPGA, MAX® V CPLD, Stratix® 10 AX FPGA, Stratix® 10 DX FPGA, Stratix® 10 GX FPGA, Stratix® 10 SX FPGA, Stratix® 10 TX FPGA, Stratix® III FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA |
|---|---|
| Offering Status | Production |
| Integrated Testbench | Yes |
| Latest Quartus Version Supported | 22.4.0 |
| Development Language | C/C++, Verilog, VHDL |
Deliverable includes Verilog source code or synthesized netlist, VHDL testbench, and bit-accurate Matlab, C or C++ simulation model
Ordering Information
Creonic ITU 25G PON LDPC Encoder and Decoder
