DVB-RCS (Digital Video Broadcasting – Interaction channel for satellite distribution systems) is an established ETSI standard for digital data transmission via satellites. It uses an 8-state double-binary turbo code that has an excellent error correction performance. This outstanding performance of the DVB-RCS turbo codes makes it the ideal candidate for further applications where high spectral efficiency is key for lowering costs.
Creonic GmbH
Key Features
- Compliant with ETSI 301 790 V1.4.1 (2005-09) (DVB-RCS)
- Support for all DVB-RCS payload block sizes (12 to 216 bytes) and code rates (1/3 to 6/7)
- Support for QPSK and 8-PSK modulation interfaces
Offering Brief
Offering Brief
| Device Family | Agilex® 3 FPGA C-Series, Agilex® 5 FPGA D-Series, Agilex® 5 FPGA E-Series, Agilex® 7 FPGA F-Series, Agilex® 7 FPGA I-Series, Agilex® 7 FPGA M-Series, Agilex® 9 FPGA Direct RF-Series, Arria® 10 GT FPGA, Arria® 10 GX FPGA, Arria® 10 SX FPGA, Arria® V GT FPGA, Arria® V GX FPGA, Arria® V GZ FPGA, Arria® V ST FPGA, Arria® V SX FPGA, Cyclone® 10 GX FPGA, Cyclone® 10 LP FPGA, Cyclone® V E FPGA, Cyclone® V GT FPGA, Cyclone® V GX FPGA, MAX® 10 FPGA, MAX® V CPLD, Stratix® 10 AX FPGA, Stratix® 10 DX FPGA, Stratix® 10 GX FPGA, Stratix® 10 SX FPGA, Stratix® 10 TX FPGA, Stratix® III FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA |
|---|---|
| Offering Status | Production |
| Integrated Testbench | Yes |
| Latest Quartus Version Supported | 22.4.0 |
| Development Language | C/C++, Verilog, VHDL |
Deliverable includes Verilog source code or synthesized netlist, VHDL testbench, and bit-accurate Matlab, C or C++ simulation model
Ordering Information
Creonic DVB-RCS Turbo Decoder
from Direct
