The Creonic AWGN Channel IP core is a noise generator capable of processing up to a maximum of 512 symbols in parallel. The IP core was developed with the aim of allowing the performance evaluation of a digital communication system in the presence of Additive White Gaussian Noise.
Creonic GmbH
Key Features
- Support for up to 256 symbols in parallel at 210 MHz
- Support for SNR (ES/N0) in the range from -10 to 41dBwith steps of 0.1 dB±~ 0.01dB
- Synchronous design with one clock
- Noise sequence periodically generated at ~264≈2x1019samples
- Based on Box-Muller algorithm and Central Limit Theorem (CLT)
Offering Brief
Offering Brief
| Device Family | Agilex® 3 FPGA C-Series, Agilex® 5 FPGA D-Series, Agilex® 5 FPGA E-Series, Agilex® 7 FPGA F-Series, Agilex® 7 FPGA I-Series, Agilex® 7 FPGA M-Series, Agilex® 9 FPGA Direct RF-Series, Arria® 10 GT FPGA, Arria® 10 GX FPGA, Arria® 10 SX FPGA, Arria® V GT FPGA, Arria® V GX FPGA, Arria® V GZ FPGA, Arria® V ST FPGA, Arria® V SX FPGA, Cyclone® 10 GX FPGA, Cyclone® 10 LP FPGA, Cyclone® V E FPGA, Cyclone® V GT FPGA, Cyclone® V GX FPGA, MAX® 10 FPGA, MAX® V CPLD, Stratix® 10 AX FPGA, Stratix® 10 DX FPGA, Stratix® 10 GX FPGA, Stratix® 10 SX FPGA, Stratix® 10 TX FPGA, Stratix® III FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA |
|---|---|
| Offering Status | Production |
| Integrated Testbench | Yes |
| Latest Quartus Version Supported | 22.4.0 |
| Development Language | C/C++, Verilog, VHDL |
Deliverable includes Verilog source code or synthesized netlist, VHDL testbench, and bit-accurate Matlab, C or C++ simulation model
Ordering Information
Creonic AWGN Channel IP core
from Direct
