As PCI Express Gen5 technology becomes the backbone of next-generation storage, the need for real-time data protection is more critical than ever. Design Gateway’s AES-XTS-STG-4x IP core delivers robust, high-speed encryption for NVMe SSDs, providing seamless real-time protection without compromising performance. Designed specifically for PCIe Gen5 environments, this IP core supports full-bandwidth encryption and decryption at speeds up to 25.6 GB/s, making it ideal for securing high-throughput data storage. Built on FPGA architecture, the AES-XTS-STG-4x IP core ensures low-latency, hardware-level encryption for mission-critical applications in data centers, enterprise storage, and secure recording systems. By encrypting data before it is written to NVMe SSDs, this solution safeguards sensitive information while maintaining the speed, efficiency, and reliability demanded by high-performance storage systems.
DesignGateway Co., Ltd.
Key Features
- High-speed data transfer and real-time encryption/decryption up to 25.6 GB/s
- Optimized for PCIe Gen5 NVMe SSD applications
- Ideal for data security in mission-critical environments like industrial and military applications
- Ensures secure data recording with AES-XTS encryption technology
- Proven encryption performance for secure storage
Offering Brief
Offering Brief
| Device Family | Agilex® 7 FPGA I-Series |
|---|---|
| Offering Status | Production |
| Design Examples Available | Yes |
| Demo | Yes |
| Latest Quartus Version Supported | 23.1.0 |
| Development Language | Encrypted VHDL |
Encrypted IP core
Reference Designs Quartus Project
Ordering Information
NET-AES256-XTS-STG-4X-IP
from Direct
NET-AES256-XTS-STG-4X-IP
from Macnica
NET-AES256-XTS-STG-4X-IP
from Uniquest
