JESD204D TRANSMITTER AND RECEIVER IP

Logic Fruit Global Technologies Inc

Select

Logic Fruit Technologies JESD204D IP core delivers enhanced lane rates to meet the growing bandwidth demands of high-performance applications. Designed with backward compatibility for JESD204C and JESD204B, our IP core ensures seamless integration with existing systems.

View Partner Website Right arrow Right arrow Partner Product Page Right arrow Right arrow Contact Now

Key Features

  • Designed according to JEDEC JESD204D Standard
  • Supports up to 24 lanes per IP cores
  • Supports new link layer using Reed-Solomon Forward Error Correction (RS-FEC)
  • Option for backward compatibility to JESD204C (supports 64B/66B encoding) and JESD204B (supports 8B/10B encoding)
  • Transport layer to support multi ADC/DAC synchronization and multiple lanes
  • Data interfaces up to 116 Gbps with PAM4 encoding and up to 58 Gbps with NRZ encoding
  • Supports subclass 0,1 and 3
  • Supports all the new features introduced in JESD204D specifications
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Arria® 10 SX SoC FPGA, Arria® 10 GT FPGA, Arria® V GZ FPGA
Offering Status Production
Integrated Testbench No
Evaluation License No
Design Examples Available No
Demo No
Compliance No
Latest Quartus Version Supported 24.3.1
Development Language VHDL

All the new features introduced in JESD204D specifications

Option for backward compatibility with JESD204C (64b/66b) and JESD204B (8b/10b) link layers
