LDPC for Flash Controller (Silicon Proven IP for Altera Devices)

Mobiveil Inc.

Select

Configurable LDPC Encoder/Decoder IP delivering industry-leading flash reliability and endurance with 50 MB/s to 9 GB/s single-instance scalability, low area/power, and support for multiple LDPC codes with on-the-fly switching. Mobiveil’s LDPC IP is a technology-independent, system-validated ECC block for flash controllers that scales from ultra-low-power mobile to enterprise SSD performance. Each instance is optimized for target codeword sizes, parity, and parallelism, with selectable memory access options and platform targets (eASIC/FPGA/40–10 nm ASIC). Deliverables include LDPC compiler & matrix-gen source, an FPGA LLR reference design (MATLAB interface), and a UVM env with encoder, error injector, and decoder.

View Partner Website Right arrow Right arrow Partner Product Page Right arrow Right arrow Contact Now

Key Features

  • Scalable LDPC architecture supporting data rates from 50 MB/s to 9.0 GB/s per single instance.
  • Flexible platform enabling customer-specific custom LDPC core generation.
  • Optimized for a wide range of codeword sizes to suit diverse applications.
  • Supports the maximum required parity for robust error correction.
  • High degree of parallelism for achieving high data-rate performance.
  • Multiple memory access options for integration flexibility.
  • Platform-specific configurations available for eASIC, FPGA, and ASIC nodes from 40 nm to 10 nm.
  • Simultaneous support for different amounts of parity in the same core.
  • Simultaneous support for multiple LDPC codes.
  • On-the-fly switching between LDPC codes without system reset.
  • Low area footprint for cost-sensitive designs.
  • Low power consumption suitable for both mobile and enterprise applications.
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Arria® II GX FPGA, Arria® V GT FPGA, Arria® V GX FPGA, Arria® V GZ FPGA, Arria® V ST SoC FPGA, Arria® V SX SoC FPGA, Cyclone® III FPGA, Cyclone® IV E FPGA, Cyclone® IV GX FPGA, Cyclone® V E FPGA, Cyclone® V GT FPGA, Cyclone® V GX FPGA, Cyclone® V SE SoC FPGA, Cyclone® V ST SoC FPGA, Cyclone® V SX SoC FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Agilex® 5 FPGAs and SoC FPGAs D-Series, Agilex® 5 FPGAs and SoC FPGAs E-Series, Agilex® 7 FPGAs and SoC FPGAs F-Series, Agilex® 7 FPGAs and SoC FPGAs I-Series, Agilex® 7 FPGAs and SoC FPGAs M-Series, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, Arria® 10 GT FPGA, Arria® 10 GX FPGA, Arria® 10 SX SoC FPGA, Cyclone® 10 GX FPGA, Cyclone® 10 LP FPGA, Stratix® 10 AX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 GX FPGA, Stratix® 10 SX SoC FPGA, Stratix® 10 TX FPGA, eASIC™ N3X Devices, eASIC™ N3XS Devices, Stratix® III FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA
Offering Status Production
Integrated Testbench Yes
Evaluation License Yes
Design Examples Available No
Demo No
Compliance No
Latest Quartus Version Supported 24.3.1
Development Language Encrypted Verilog, Verilog

Source Code for LDPC Compiler

Source Code for LDPC Matrix Generation Software

FPGA based LLR generation reference design with MATLAB interface

UVM verification env with encoder, error injector and decoder instantiated

IP User Guide

Synthesis Guide

Ordering Information

NA

from Direct

Order Now

Documentation & Resources

design hub icon LDPC for Flash - Product Brief
