The ASCON-F IP core is a compact, high-throughput hardware engine implementing the lightweight authenticated encryption with associated data (AEAD) and hashing algorithms described in the Ascon v1.2 specification.

A single instance of the ASCON-F IP core can encrypt or decrypt data using the Ascon-128 and Ascon-128a functions or perform Cryptographic hashing Hash per the Ascon-Hash and Ascon-Hasha functions. The mode of operation (encryption or decryption, and Ascon function), as well as the encryption key and nonce values, are run-time programmable and can be changed per block of input data. The core uses simple input and output interfaces, that can be optionally bridged to AXI4-Stream, or to AXI4 Memory Mapped master or slave ports using bridges separately available from CAST.

The core synthesizes to approximately 11k gates and is able to run at frequencies exceeding 2 GHz in modern ASIC technologies. Ignoring overheads related to input padding a...

The ASCON-F IP core is a compact, high-throughput hardware engine implementing the lightweight authenticated encryption with associated data (AEAD) and hashing algorithms described in the Ascon v1.2 specification.

A single instance of the ASCON-F IP core can encrypt or decrypt data using the Ascon-128 and Ascon-128a functions or perform Cryptographic hashing Hash per the Ascon-Hash and Ascon-Hasha functions. The mode of operation (encryption or decryption, and Ascon function), as well as the encryption key and nonce values, are run-time programmable and can be changed per block of input data. The core uses simple input and output interfaces, that can be optionally bridged to AXI4-Stream, or to AXI4 Memory Mapped master or slave ports using bridges separately available from CAST.

The core synthesizes to approximately 11k gates and is able to run at frequencies exceeding 2 GHz in modern ASIC technologies. Ignoring overheads related to input padding and core initialization, the throughput ranges from 5.3 to 16 bits/cycle depending on the mode and function, which at 2 GHz translates to 10.6 to 32 Gbps. The processing throughput can be further scaled by instantiating the core multiple times.

The core is designed for ease of use and integration and adheres to industry-best coding and verification practices. Technology mapping and timing closure are trouble-free, as the core contains no multi-cycle or false paths and uses only rising-edge-triggered D-type flip-flops, no tri-states, no SRAMs, and a single-clock/reset domain.

View Partner Website Right arrow Right arrow Partner Product Page Right arrow Right arrow Contact Now

Key Features

  • Implements Ascon v1.2 AEAD and hashing: Ascon-128/128a encryption, Ascon-Hash/Hasha, plus Ascon-Xof, Xofa, and 80pq variants available on request.
  • Run-time selectable operation mode, encryption key and nonce
  • Compact ASCON-F core: ~11k gates, over 2GHz in ASICs, with throughput from 5.3 to 16 bits/cycle across AEAD and hashing modes.
  • Easy to integrate: fully synchronous, clean timing, simple I/O with AMBA® or DMA, and delivered as tech-agnostic VHDL/Verilog IP for FPGA or ASIC.
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Arria® V GT FPGA, Arria® V GX FPGA, Arria® V GZ FPGA, Arria® V ST SoC FPGA, Arria® V SX SoC FPGA, Cyclone® IV E FPGA, Cyclone® IV GX FPGA, Cyclone® V E FPGA, Cyclone® V GT FPGA, Cyclone® V GX FPGA, Cyclone® V SE SoC FPGA, Cyclone® V ST SoC FPGA, Cyclone® V SX SoC FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Agilex® 5 FPGAs and SoC FPGAs D-Series, Agilex® 5 FPGAs and SoC FPGAs E-Series, Agilex® 7 FPGAs and SoC FPGAs F-Series, Agilex® 7 FPGAs and SoC FPGAs I-Series, Agilex® 7 FPGAs and SoC FPGAs M-Series, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, Arria® 10 GT FPGA, Arria® 10 GX FPGA, Arria® 10 SX SoC FPGA, Cyclone® 10 GX FPGA, Cyclone® 10 LP FPGA, MAX® 10 FPGA, Stratix® 10 AX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 GX FPGA, Stratix® 10 SX SoC FPGA, Stratix® 10 TX FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA
Offering Status Production
Integrated Testbench Yes
Evaluation License Yes
Design Examples Available Yes
Demo No
Compliance Yes
Latest Quartus Version Supported 24.3.1
Development Language Encrypted Verilog, Encrypted VHDL, Verilog, VHDL

Verilog/System Verilog, Encrypted Verilog/System Verilog, VHDL, Encrypted VHDL, or FPGA netlist

System Verilog testbench

Comprehensive documentation

Sample synthesis and simulation scripts

Software model

Ordering Information

ASCON-F

from Direct

$0.00

Order Now

Documentation & Resources

design hub icon ASCON-F datasheet
