syn1588® Clock_M

Overview Key Features Offering Brief What's Included Ordering Information Documentation & Resources Markets

The syn1588® Clock_M IP core family provides highly accurate IEEE1588 compliant clock synchronization functions. The syn1588® Clock_M IP cores are suited for direct integration to an Ethernet MAC. Either one or up to four network interfaces can be connected. A large variety of network line speeds are supported. There is an AXI4 Lite CPU interface for communication with the host processor executing the PTP Stack.

The syn1588® Clock_M IP core family offer all functions required to implement a high-accuracy PTP node. The feature-rich architecture allows creating of PTP slave and PTP master nodes. It's sophisticated hardware clock architecture allow fine-grained clock servo control. All published IEEE1588 standards are supported.

A typical application example is the syn1588® PCIe NIC. This standard PCIe Ethernet network interface card is made up of a single FPGA that includes the syn1588® Clock_M IP core as well as the Ethernet MAC and the PCIe interface.

View Partner Website

Contact Now

Contact

LeadSource

ASAP Account ID

Record Type Name

Key Features

High Accuracy clock synchronization
Timestamp hardware event signals - EVENT function
Generate on-time hardware events (signals) - TRIGGER function
Generate peridical hardware signsls (clocks) - PERIOD function
Generate and read IRIG-B data stream
1PPS In/Out
Linux and Windows driver optionally available

Offering Brief

Device Family	Agilex™ 3 FPGA C-Series, Agilex™ 5 FPGA D-Series, Agilex™ 5 FPGA E-Series, Agilex™ 7 FPGA F-Series, Agilex™ 7 FPGA I-Series, Agilex™ 7 FPGA M-Series, Arria® 10 GT FPGA, Arria® 10 GX FPGA, Arria® 10 SX FPGA, Arria® V GT FPGA, Arria® V GX FPGA, Arria® V GZ FPGA, Arria® V ST FPGA, Arria® V SX FPGA, Cyclone® IV GX FPGA, Cyclone® V E FPGA, Cyclone® V GT FPGA, Cyclone® V GX FPGA, Cyclone® V SE FPGA, Cyclone® V ST FPGA, Cyclone® V SX FPGA, Stratix® 10 GX FPGA, Stratix® 10 SX FPGA, Stratix® III FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Stratix® V E FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA
Offering Status	Production
Integrated Testbench	No
Evaluation License	No
Design Examples Available	Yes
Demo	Yes
Compliance	No
Intertop	IEEE1588ISPCS Plug Fests attended since 15+ years now
Latest Quartus Version Supported	25.1.0
OS Support	Linux,Windows
Development Language	Encrypted VHDL, VHDL
