The Compute Express Link™ (CXL) 3.x IP Core is designed to meet the demands of next-generation heterogeneous computing systems, enabling high-speed, low-latency interconnect between CPUs, GPUs, FPGAs, DPUs, accelerators, memory expanders, and smart I/O devices.

Supporting the CXL 3.0 specification, this IP delivers backward compatibility with CXL 1.x/2.0, advanced memory pooling, and fabric capabilities, making it ideal for data centers, AI/ML workloads, and HPC environments.

View Partner Website

Partner Product Page

Contact Now

Contact Qbit Labs Incorporation

LeadSource

ASAP Account ID

Record Type Name

Key Features

CXL Protocol Support: CXL.io, CXL.cache, and CXL.mem coherence protocols with support for Type 1, Type 2, and Type 3 devices.
Backward Compatibility: Fully compliant with CXL 1.1 and CXL 2.0 for smooth ecosystem integration.
High Bandwidth: Leverages PCIe 6.0 physical layer for up to 64 GT/s per lane with PAM4 signaling.
Scalability: Supports up to 16-lane configurations for maximum throughput and bandwidth aggregation.
Flexible Integration: Modular design supporting multiple SoC and FPGA platforms with AXI interfaces.

Offering Brief

Device Family	Agilex® 5 FPGAs and SoC FPGAs E-Series, Agilex® 7 FPGAs and SoC FPGAs F-Series, Agilex® 7 FPGAs and SoC FPGAs I-Series, Agilex® 7 FPGAs and SoC FPGAs M-Series
Offering Status	Production
Integrated Testbench	No
Evaluation License	Yes
Design Examples Available	Yes
Demo	No
Compliance	Yes
Latest Quartus Version Supported	24.3.1
Development Language	Encrypted Verilog, Verilog

Synthesizable encrypted RTL source code

Embedded firmware / low-level SW

CXL Controller Requirements Specification (CRS)

CXL Controller Micro-Architecture Specification

CXL Controller Programmer’s Reference Manual (PRM)

Synthesizable RTL source code (Verilog/SystemVerilog preferred; VHDL if requested) covering: CXL.io (PCIe-compatible Transaction/Data Link/Port layers). CXL.cache and CXL.mem protocols (link layer, transaction layer, coherency handling). Arb/MUX logic for protocol multiplexing. Low-latency features (e.g., alternate protocol negotiation, vLSMs, zero-added-latency paths in CXL 3.x). Reliability (RAS: FEC, CRC, poison handling), error reporting, AER.
