Creonic IEEE 802.11ad WiGig LDPC Decoder

Creonic GmbH

Select

The Creonic WiGig LDPC decoder is designed in particular to deliver highest throughputs in the multi-gigabit domain with a small footprint. At the same time it provides outstanding error correction performance, resulting in a low energy consumption and increasing range of wireless transmission. Its unique pipeline architecture can be customized at design-time to deliver best performance on any target technology (ASIC technology nodes and FPGAs).

View Partner Website Right arrow Right arrow Partner Product Page Right arrow Right arrow Contact Now

Key Features

  • Compliant with IEEE 802.11ad
  • Support for 672 bits codewords and all LDPC code rates (1/2, 5/8, 3/4, 13/16)
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Arria® 10 SX SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, MAX® V CPLD, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Cyclone® V E FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Stratix® III FPGA
Offering Status Production
Integrated Testbench Yes
Evaluation License No
Design Examples Available No
Demo No
Compliance No
Latest Quartus Version Supported 22.4.0
Development Language C/C++, Verilog, VHDL

Deliverable includes Verilog source code or synthesized netlist, VHDL testbench, and bit-accurate Matlab, C or C++ simulation model​

Ordering Information

Creonic IEEE 802.11ad LDPC Decoder

from Direct

Order Now

Documentation & Resources

design hub icon Product Brief
