CCSDS LDPC Encoder and Decoder

Creonic GmbH

Select

The Creonic CCSDS LDPC IP cores support the LDPC coding scheme as defined by the CCSDS standard. The LDPC code with single rate 223/255 was specifically designed for Near-Earth missions, but the excellent error correction performance also makes it an ideal solution for a wide variety of high-throughput applications.

View Partner Website Right arrow Right arrow Partner Product Page Right arrow Right arrow Contact Now

Key Features

  • Support for code rate 223/255 (7136/8160)
  • Coded block size 8160 bits
  • Compliant with “TM Synchronization and Channel Coding, Recommended Standard, CCSDS 131.0 B-3, Blue Book, September 2017” ​
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Arria® 10 SX SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, MAX® V CPLD, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Cyclone® V E FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Stratix® III FPGA
Offering Status Production
Integrated Testbench Yes
Evaluation License No
Design Examples Available No
Demo No
Compliance No
Latest Quartus Version Supported 22.4.0
Development Language C/C++, Verilog, VHDL

Deliverable includes Verilog source code or synthesized netlist, VHDL testbench, and bit-accurate Matlab, C or C++ simulation model​

Ordering Information

Creonic CCSDS LDPC Encoder and Decoder

from Direct

Order Now

Documentation & Resources

design hub icon Product Brief
