DESPI - Enhanced Serial Peripheral Interface (eSPI)

DCD-SEMI

Select

The DESPI is a fully configurable eSPI master/slave device supporting all features described in Enhanced Serial Peripheral Interface Base Specification rev. 1.0. The DESPI master is to be used by the microcontroller to communicate with eSPI peripheral devices. The DESPI slave is to be used as an eSPI peripheral device, e.g. an Embedded Controller attached to the Intel CPU system.

View Partner Website Right arrow Right arrow Partner Product Page Right arrow Right arrow Contact Now

Key Features

  • Compliant with eSPI base specification as defined in Enhanced Serial Peripheral Interface (eSPI) Specification rev.1.0
  • Supports Master and Slave Modes
  • Supports Single, Dual and Quad modes
  • Supports TX and RX operation as per specs
  • Support for Command Phase, Turn-Around Phase, Response Phase
  • Baud Rate selection
  • Slave Triggered Transactions
  • Power management Event
  • Interrupts and Alerts
  • In-band reset
  • Support for multiple channels: Peripheral channel, Virtual wire Channel, OOB Message (Tunneled SMBus) Channel, Run-time Flash Access Channel
  • Various Master/Slave errors detection
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Arria® 10 SX SoC FPGA, Cyclone® III FPGA, Cyclone® IV GX FPGA, Agilex® 5 FPGAs and SoC FPGAs E-Series, MAX® 10 FPGA, Cyclone® V SX SoC FPGA, Arria® V GZ FPGA, Agilex® 9 FPGAs and SoC FPGAs Direct RF-Series, MAX® V CPLD, Agilex® 7 FPGAs and SoC FPGAs I-Series, Arria® V SX SoC FPGA, Stratix® 10 DX FPGA, Stratix® 10 SX SoC FPGA, Agilex® 7 FPGAs and SoC FPGAs M-Series, Cyclone® V GT FPGA, Arria® 10 GT FPGA, Arria® V ST SoC FPGA, Arria® 10 GX FPGA, Stratix® 10 TX FPGA, Cyclone® V SE SoC FPGA, Stratix® IV E FPGA, Stratix® IV GX FPGA, Arria® V GX FPGA, Cyclone® V E FPGA, Agilex® 3 FPGAs and SoC FPGAs C-Series, Cyclone® V GX FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA, Cyclone® V ST SoC FPGA, Agilex® 5 FPGAs and SoC FPGAs D-Series, Stratix® 10 GX FPGA, Arria® V GT FPGA, Cyclone® 10 LP FPGA, Agilex® 7 FPGAs and SoC FPGAs F-Series, Cyclone® 10 GX FPGA, Stratix® 10 AX SoC FPGA, Cyclone® IV E FPGA, Stratix® III FPGA
Offering Status Production
Integrated Testbench Yes
Evaluation License Yes
Design Examples Available Yes
Demo No
Compliance No
Latest Quartus Version Supported 25.1.1
Development Language Encrypted Verilog, Verilog

HDL Source Code

Testbench environment - automatic simulation macros, tests with reference responses

Synthesis scripts

Technical documentation

12 months of technical support

Ordering Information

DESPI

from Direct

Order Now

Documentation & Resources

design hub icon Datasheet
