BoardTrace offers an easy and smart way to organize and view connected schematic netlists and FPGAs. Instead of manually comparing two lists with hundreds of pins for each connector or browsing through a netlist file, you can load all the PCB netlist files into BoardTrace and define how boards are connected. BoardTrace provides a connector view, a trace view, and an extended netlist to show how components connect across multiple boards. FPGAs and microcontrollers are visualized as virtual boards to show pin-to-pin connectivity.
