Warping Engine IP Core

TES Electronic Solutions GmbH

Select

TES Warping Engine is a specialized IP core for arbitrary high-performance re-mapping of bitmaps from memory to memory or memory to AXI4 Stream. Applications are for example pre-warping for projection on head-up displays (HUDs) or fisheye-correction of camera images. The image transformation is controlled via a highly compressed Look Up Table (LUT) allowing arbitrary transformations. The IP core adapts to different bus interfaces like AMBA APB and AHB/AXI as well as the Altera Avalon bus interface at different bus width.

View Partner Website Right arrow Right arrow Partner Product Page Right arrow Right arrow Contact Now

Key Features

  • Image warping / transformation
  • Scaling
  • Cropping
  • Output streaming
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Agilex® 3 FPGA C-Series, Agilex® 5 FPGA D-Series, Agilex® 5 FPGA E-Series, Agilex® 7 FPGA F-Series, Agilex® 7 FPGA I-Series, Agilex® 7 FPGA M-Series, Agilex® 9 FPGA Direct RF-SeriesArria® 10 GT FPGA, Arria® 10 GX FPGA, Arria® 10 SX FPGA, Arria® V GT FPGA, Arria® V GX FPGA, Arria® V GZ FPGA, Arria® V ST FPGA, Arria® V SX FPGA, Cyclone® 10 GX FPGA, Cyclone® 10 LP FPGACyclone® III FPGA, Cyclone® III LS FPGA, Cyclone® IV E FPGA, Cyclone® IV GX FPGA, Cyclone® V E FPGA, Cyclone® V GT FPGA, Cyclone® V GX FPGA, Cyclone® V SE FPGA, Cyclone® V ST FPGA, Cyclone® V SX FPGA, MAX® 10 FPGA, MAX® V CPLD, Stratix® 10 AX FPGAStratix® 10 DX FPGA, Stratix® 10 GX FPGA, Stratix® 10 SX FPGA, Stratix® 10 TX FPGA, Stratix® III FPGA, Stratix® IV E FPGA, Stratix® IV GT FPGA, Stratix® IV GX FPGA, Stratix® V E FPGA, Stratix® V GS FPGA, Stratix® V GX FPGA
Offering Status Production
Evaluation License Yes
Latest Quartus Version Supported 24.1.0
OS Support bare metal,Linux
Development Language C/C++, Encrypted VHDL, VHDL

QSys component

baremetal driver source code

Tools for LUT generation (also as source code)

Documentation

Ordering Information

Warping Engine

from Direct

Get Pricing and Availability
