MIPI DSI-2

Overview Key Features Offering Brief What's Included Ordering Information Markets

Qbit Labs Incorporation

Member

Qbit Labs’ MIPI DSI-2 IP Core and Controller provides high-performance, low-power display connectivity for advanced embedded and high-resolution display systems. Fully compliant with the MIPI DSI-2 specification and supporting both C-PHY and D-PHY interfaces, the solution enables scalable, high-bandwidth video data transfer with optimized power efficiency.

Designed for seamless integration with FPGA and SoC platforms, the IP features a flexible and configurable architecture supporting multiple lanes, virtual channels, and diverse pixel formats. It is well suited for automotive displays, industrial HMIs, AR/VR systems, medical displays, and next-generation embedded graphics applications, helping reduce integration complexity and accelerate time-to-market.

View Partner Website

Partner Product Page

Contact Now

Contact Qbit Labs Incorporation

LeadSource

ASAP Account ID

Record Type Name

Key Features

Full compliance with MIPI DSI-2 specification and Support for C-PHY and D-PHY physical layers
Scalable multi-lane architecture for high-resolution displays and High-bandwidth, low-latency video data transmission
Support for multiple virtual channels and Broad pixel format compatibility
AXI4-Stream interface for video data and AXI4-Lite interface for control and configuration
Low-power, resource-efficient FPGA implementation and Flexible and configurable architecture for easy system integration

Offering Brief

Device Family	Agilex® 3 FPGAs and SoC FPGAs C-Series, Agilex® 5 FPGAs and SoC FPGAs E-Series, Agilex® 7 FPGAs and SoC FPGAs F-Series, Agilex® 7 FPGAs and SoC FPGAs I-Series, Agilex® 7 FPGAs and SoC FPGAs M-Series
Offering Status	Production
Integrated Testbench	No
Evaluation License	Yes
Design Examples Available	Yes
Demo	No
Compliance	No
Latest Quartus Version Supported	24.3.1
Development Language	Encrypted Verilog, Verilog
