"The Agilex™ 7 R24C 3U-VPX Plug-in Module is a rugged, high-performance compute platform designed for military and aerospace applications. Powered by the Altera Agilex™ 7 R24C SoC FPGA (AGFB014), the board integrates a Quad-core 64-bit Arm Cortex-A53 up to 1.50 GHz and up to 2.7M logic elements, making it ideal for data-intensive tasks including secure communication.
The plug-in module is equipped with 8GB HPS DDR4, 8GB FPGA DDR4 with ECC, and dual 144MB QDR-IV memory, ensuring real-time data processing and low-latency response. VPX front-panel connectivity includes USB 2.0 through USB Type-C Connector and Debug UART through 3-Pin Header. While the backplane offers high-speed transceivers supporting 40G/10G/1G Ethernet and PCIe Gen3/PCIe Gen 2 interfaces. With support for multiple I/O standards and an MT Ferrule optical interface (28.125Gbps).
Designed in the 3U-VPX form factor (160mm x 100mm), the solution includes features such as temperature Sensor, Elapse Time Counter EEPROM and MCU for System Management."
