"The Agilex™ 7 R24C SOSA-aligned 3U-VPX Plug-in Module is a rugged, high-performance embedded computing platform engineered for aerospace, defense, radar, and electronic warfare applications where real-time data processing and open architecture standards are essential. Powered by the Altera Agilex™ 7 R24C SoC FPGA with a quad-core 64-bit ARM Cortex-A53 processor running up to 1.50 GHz and up to 2.7 M logic elements, the module delivers robust processing capability for demanding workloads.
Designed to conform with Sensor Open Systems Architecture (SOSA) standards, the 3U-VPX plug-in module provides extensive memory and storage, including 8 GB DDR4 ECC for both HPS and FPGA, dual 144 Mb QDR-IV for high-speed buffering, expandable 32 GB eMMC, and 1 Gb QSPI flash, along with onboard EEPROM for configuration retention.
Front panel features include USB 2.0 via USB Type-C, Debug UART through a 3-pin header, and 1 G Ethernet through a 9-pin header for convenient connectivity and maintenance. On the VPX backplane, high-speed transceivers support 40GBASE-KR4, 10GBASE-KR, and 1 G Ethernet, while PCIe Gen3 x8 expansion lanes deliver high-bandwidth data transfer.
The module also includes multiple SDI IN/OUT paths through coaxial connectors and up to eight fiber optic transceiver links delivering up to 28.125 Gbps via Firefly connectors, providing versatile high-speed I/O for modern defense systems. Built in the standard 3U-VPX form factor (160 mm × 100 mm), the solution incorporates advanced system management features including a VITA 46.11 Tier-3 compliant board management controller, temperature sensing, clock synthesizers, elapsed time counter, and voltage monitoring for rugged embedded deployments."
