Multi-Algorithm SHA3 Hash Engine IP Core (SHA3-IP)

DesignGateway Co., Ltd.

Select

The SHA3-IP core is a highly efficient, pure-hardware hash engine that implements all six algorithms defined in the FIPS PUB 202 standard (SHA3-224, SHA3-256, SHA3-384, SHA3-512, SHAKE128, and SHAKE256) within a single integrated core. It provides ultra-high throughput exceeding 17.5 Gbps and allows dynamic algorithm selection at runtime. It is ideal for accelerating secure communications, data integrity, and authentication applications on Altera FPGAs without CPU overhead.

Key Features

  • Achieves over 17.5+ Gbps throughput @ 316 MHz
  • Byte oriented implementation compatible with FIPS 202
  • Customizable output length for SHAKE algorithm.
  • Dynamic algorithm and output length selection at runtime using control interface
  • Input/Output Data Interface: 64-bit AXI4-Stream
  • 1344-bit Parallel Output Interface for single-cycle flat hash reading
Expand Close
Keyfeatures main image

Offering Brief

Offering Brief

Device Family Agilex™ 7 FPGA I-Series, Arria® 10 SX FPGA
Offering Status Development
Integrated Testbench No
Evaluation License No
Design Examples Available No
Demo No
Compliance No
Latest Quartus Version Supported 23.1.0
Development Language Encrypted VHDL

Comprehensive User Manual & Verification Guide

Free Evaluation Bitstream (available for rapid on-board testing prior to purchase)

Complete Reference Design & Demo Project (Quartus project files for supported FPGA development boards)
