Adjustable Clock

Full standalone hardware only solution of an adjustable Counter Clock

Offerings Image

Advanced Formal Verification

This is the advanced course of a two course formal verification progression. It assumes comprehensive knowledge of “Applied Formal Verification” and applies formal methods to the problems that dominate real Altera SoC designs.

Offerings Image

Advanced FPGA Design Methodologies and Techniques

This comprehensive course consolidates the full breadth of advanced FPGA design knowledge into a single intensive program.

Offerings Image

Advanced Platform Designer

This advanced course elevates engineers from solid Platform Designer users to expert-level practitioners.

Offerings Image

Advanced SoC System Design & Verification

This advanced course brings together all disciplines of Altera SoC FPGA design into a comprehensive system design and verification experience.

Offerings Image

Advanced Verilog Design Techniques

This course teaches designers to write professional, synthesizable RTL code using industry-standard Verilog HDL practices.

Offerings Image

Advanced VHDL

This advanced, hands-on course is designed for experienced FPGA engineers who want to deepen their mastery of VHDL.

AES - Advanced Encryption Standard Engine

The AES encryption IP core implements hardware Rijndael encoding and decoding in compliance with the NIST Advanced Encryption Standard. It processes 128-bit blocks, and is programmable for 128-, 192-, and 256-bit key lengths. Two architectural versions are available to suit system requirements. The Standard version (AES-S) is more compact, using a 32-bit datapath and requiring 44/52/60 clock cycles for each data block (128/192/256-bit cipher key, respectively). The Fast version (AES-F) achieves higher throughput, using a 128-bit datapath and requiring 11/13/15 clock cycles for each data block. Various cipher modes can be supported (CBC, CFB, CTR, ECB, LRW, and OFB). The core works with a pre-expanded key, or with optional key expansion logic. The AES core is a fully synchronous design and has been evaluated in a variety of technologies. It is available optimized for ASICs or FPGAs, with complete deliverables.

AES 128 IP

AES-128 IP supports ECB mode for both encryption and decryption, processing 128-bit data blocks in a constant 11 clock cycles. It delivers 11.6 Mbps per MHz, achieving up to 4.65 Gbps at 400 MHz. Designed to enhance the security of data storage and networking IP cores, it enables secure, efficient, and high-performance applications.
