Design & Prototyping

We offer end-to-end support for electronics and hardware development, starting with conceptual design and ROI/TCO analysis. Our services include schematic and PCB layout, prototyping and testing, CE/RED certification, and small series production with support and ticketing. We specialise in FPGA-based solutions and work with a trusted EU-based partner network. Our experience spans auxiliary power supplies, control units, converters, radio electronic devices, and telematics, across industries such as automotive, semiconductors, and industrial manufacturing.

Offerings Image

Design flow consultancy

Writing code for your FPGA is not the only thing that needs to be done. It needs to be embedded on a board with the right pinning, and it needs to communicate with the outside world as well, through protocols, registers and what not. . Also there can be embedded softcores like ARM, RISC or Nios® cores running their own firmware. And also your design needs to be verified. Using UVM or some other method. This usually means that there is a lot of communication with other designers, within and outside your own discipline. Especially when designs get bigger this can become complex. Dizain-Sync can help streamline these processes, and find solutions for bottlenecks and issues in your design flow. Examples include: how to do proper data management when working in a large team, how to specify the hardware/software interfaces, how to deliver your design data to the rest of the team or the business systems, like PDM, PLM and ERP, etc. etc.

Offerings Image

Design Services - full system architecture, PCB, mechanical, software

Design Services - FPGA full system architecture and implementation, PCB, mechanical, software

Offerings Image

Design Verification

Logic Fruit delivers comprehensive, end-to-end design verification services for IPs, FPGAs, ASICs, and SoCs—ensuring your designs work flawlessly the first time. Our expertise spans UVM testbenches, constrained-random and scenario-driven testing, advanced coverage analysis, and protocol/IP validation across high-speed standards such as PCIe, CXL, JESD204, ARINC 818, Ethernet, USB, and DisplayPort. We provide robust, reliable, and standards-compliant solutions that reduce risk, cut costs, and accelerate time-to-market.

DISPLAY PORT IPs

Logic Fruit's Display Port Transmitter & Receiver IP Cores support multiple line rates up to 8.1 Gbps. The IP cores have been developed as per Display Port specifications DP2.0/eDP1.5.

DVB-C / J.83abc Modulator

The CMS0021 single-channel DVB-C modulator / J83 modulator is fully compliant with the European, US and Japanese downlink cable standards DVB-C EN 300 429 and ITU J83 Annexes A/B/C (including DOCSIS 1.1/2.0).

DVB-C / J83abc Demodulator

The CMS0022 Cable (QAM) Demodulator is fully compliant with the European, US and Japanese downlink cable standards DVB-C EN 300 429 and ITU J83 Annexes A/B/C (including DOCSIS 1.1/2.0).

DVB-CID Modulator

The CMS0069 DVB-CID modulator is an integrated modulator and channel-coder core designed specifically to address the requirements of the ETSI DVB-CID carrier identification standard (EN103129).

DVB-S / DVB-DSNG Demodulator

The CMS0048 has been designed from the ground-up for high-speed and gate-efficient implementation on FPGA and ASIC platforms and offers very high performance when combined with either the integrated FEC decoder or an external advanced FEC decoder. The demodulator provides an adaptable starting point for receiver sub-systems to be used in both the current and next-generation of digital TV set-top-boxes
